Milwaukee Inspection Cameras: Which One to Buy
Milwaukee makes a small family of inspection cameras, and they are built for trades rather than hobbyists: the M12 M-Spector 360 for walls and plumbing, a battery-powered M-Spector that runs on AAs, two automotive borescopes with thin dual cameras, and a 65-foot drain camera that uses your phone or a Milwaukee monitor as its screen. Here is what each one does, what it does not, and which to buy.
- 5 picks compared
- Specs checked against maker data
- No paid placements
GaugeGrade is reader-supported. When you buy through links on our site we may earn an affiliate commission at no extra cost to you. We only recommend gear we have researched against verified manufacturer specifications.
- 1Most people should buy the M12 M-Spector 360 (2323-21): a 4.3-inch screen, a 10 mm head, 720p recording and a 4 ft cable, on the M12 battery platform.
- 2For engines, the 5 mm dual-camera M12 Auto Technician Borescope (3150-20) goes where the 10 mm M-Spector cannot; the Auto Shop version (3151-21) adds a 5.5-inch touchscreen and Wi-Fi sharing.
- 3Milwaukee publishes no waterproof rating for the M-Spector cameras, and their manuals say never to immerse the tool; only the Auto Shop borescope's sell sheet lists IP67.
- 1Best overallMilwaukee M12 M-Spector 360 4 ft Inspection Camera (2323-21)
- 2Best without M12 batteriesMilwaukee M-Spector 4 ft Inspection Camera (2319-20)
- 3Best for enginesMilwaukee M12 Auto Technician Borescope (3150-20)
- 4Best for shopsMilwaukee M12 Auto Shop Borescope with Wi-Fi (3151-21)
- 5Best for drainsMilwaukee M12 65 ft Ultra Flex Compact Inspection Camera Kit (3318-22A)
What we recommend
Compare the key specs side by side, then read the full notes on each pick below.
- Screen
- 4.3"
- Camera
- 10 mm, 720p, 4 ft cable
- Power
- M12 battery
- Screen
- 4.3"
- Camera
- 10–11 mm, 720p, 4 ft cable
- Power
- 4 AA batteries(included)
- Screen
- 4.3"
- Camera
- 5 mm front + side, 720p, 3 ft cable
- Power
- M12(bare tool)
- Screen
- 5.5"touchscreen
- Camera
- 5 mm front + side, 720p, 5 ft cable
- Power
- M12 kit(battery and charger)
- Screen
- None: phone or tablet app, or a Milwaukee monitor
- Camera
- 16 mm, 1080p, 65 ft push cable
- Power
- M12 kit(2 batteries)
Milwaukee M12 M-Spector 360 4 ft Inspection Camera (2323-21)
Walls, cabinets, HVAC and general jobsite inspection
- Screen
- 4.3"
- Camera
- 10 mm, 720p, 4 ft cable
- Power
- M12 battery
- Screen housing turns, and the image rotates 180° at the push of a button
- 3-level zoom and 5 brightness modes
- Records to the included 32 GB microSD card
- Hook, mirror, magnet and plumbing ball included; 5-year tool warranty
- 10 mm head is too big for small openings
- Check whether the listing includes an M12 battery and charger
The Milwaukee to buy for walls, cabinets and general jobsite work. The screen turns and the image flips, so the picture is always the right way up; it records to microSD, and the M12 battery is one you probably already own.
It's a 10 mm, front-only camera on a 4 ft cable, so small holes and anything around a corner need one of the specialist cameras below.
Based on the maker's specifications and manual and the published reviews linked below, not on our own test of this unit.
Setup, everyday use and what others found
Setup & use · per the maker
- Runs on an M12 battery. Milwaukee's -21 kit includes a CP2.0 battery and charger, but the Amazon listing doesn't say whether this one does.
- 4.3-inch screen that turns about 270°, plus a button that flips the image 180°, so you can set the picture upright whichever way the camera lies.
- 10 mm, 720p camera on a 4 ft cable; Milwaukee says the head fits a patchable 3/8-inch hole in drywall. There's no longer cable for this model; the 10 ft version is the 2324-21.
- 3 zoom levels and 5 brightness modes. Photos and video save to a microSD card formatted FAT32, and Milwaukee includes a 32 GB card.
- Hook, mirror, magnet and plumbing-ball attachments in the box. Drop-rated to 1 m, works from 14 to 104 °F, and switches off after 5 minutes idle.
- No IP rating: the manual says never to immerse it or let liquid run down the cable, and to shut off the circuit breakers and make sure pipes carry no charge before you work.
What others found
Several Home Depot reviewers praise the clear picture, though one calls the video very poor. Two wish the tip could bend, since you shape the cable by hand; one says getting files off needs an SD card reader, and another wishes for a port or Bluetooth. Some reviews carry Home Depot's Seed Program label.
Milwaukee M-Spector 4 ft Inspection Camera (2319-20)
Anyone who wants Milwaukee's camera without buying into the M12 platform
- Screen
- 4.3"
- Camera
- 10–11 mm, 720p, 4 ft cable
- Power
- 4 AA batteries (included)
- Runs on four AA batteries, included
- Digital 180° image rotation and 3-level zoom
- Mirror and plumbing ball included
- No recording or memory card on Milwaukee's page or in the manual (its launch release lists image capture)
- No hook or magnet in the box
The only camera here that doesn't need an M12 battery: four AAs run a 4.3-inch screen and a 720p camera on a 4 ft cable.
Milwaukee's page and manual describe no recording, and it comes with a mirror and plumbing ball but no hook or magnet.
Based on the maker's specifications and manual and the published reviews linked below, not on our own test of this unit.
Setup, everyday use and what others found
Setup & use · per the maker
- Runs on four AA batteries, included. In the box: mirror and plumbing-ball attachments; no hook or magnet.
- 4.3-inch screen with a digital 180° image flip and 3 zoom levels; the LEDs cycle through four brightness levels or off.
- 720p camera on a 4 ft cable. Milwaukee's product page gives a 10 mm head; the latest manual says 11 mm.
- Milwaukee's product page and manual describe no photo or video recording and no memory card, although its launch press release lists image capture.
- Drop-rated to 1 m, works from 14 to 104 °F and switches off after 5 minutes idle. No IP rating; the manual says never to immerse it.
What others found
We found no independent hands-on test and no owner reviews we could read for this model.
Milwaukee M12 Auto Technician Borescope (3150-20)
Cylinders, glow-plug holes, injector ports and other narrow engine openings
- Screen
- 4.3"
- Camera
- 5 mm front + side, 720p, 3 ft cable
- Power
- M12 (bare tool)
- 5 mm front and side cameras for narrow access points
- HEAT SENSE warns and shuts down if the area is too hot
- Screen rotates about 270°; microSD card preinstalled
- Hard case included
- Bare tool: no battery or charger
- Short 3 ft cable (Milwaukee sells a 5 ft cable that fits)
The Milwaukee for looking inside engines. A 5 mm probe with front and side cameras goes through glow-plug and injector openings the 10 mm M-Spector can't, and it's the only camera here that two publications have tested hands-on.
It's a bare tool with a short 3 ft cable, and the 720p picture is modest for the money.
Based on the maker's specifications and manual and the published reviews linked below, not on our own test of this unit.
Setup, everyday use and what others found
Setup & use · per the maker
- Bare tool: runs on an M12 battery, sold separately. In the box: the tool, the 5 mm camera cable and a hard case.
- 5 mm head with front and side cameras, 720p, on a 3 ft cable. The cable is field-replaceable, and Milwaukee's 5 ft cable (48-53-3151) also fits.
- 4.3-inch screen that turns about 270°, with digital zoom and five LED brightness levels.
- Photos and video save to a microSD card that comes preinstalled; Milwaukee's launch release gives it as 32 GB.
- HEAT SENSE warns you and shuts the camera down if the area is too hot. Rated to work from 14 to 125 °F, with the camera good to 140 °F; drop-rated to 3.3 ft.
- Milwaukee lists it for indoor use with no IP rating: the manual says never to immerse it, and to keep the camera and cable away from gas, corrosive or oily substances.
What others found
Pro Tool Reviews tested it with a diesel mechanic: the 5 mm head fit through the injector opening where his usual shop camera was too big to reach the cylinder. His only drawback was that the display can't be separated from the tool.
The Drive's reviewer, using a unit Milwaukee supplied, found the picture far better than phone borescopes and the battery life strong; his complaints were the price, the cost of a replacement cable and 720p rather than 1080p.
Milwaukee M12 Auto Shop Borescope with Wi-Fi (3151-21)
Repair shops that send inspection photos and video to customers for approval
- Screen
- 5.5" touchscreen
- Camera
- 5 mm front + side, 720p, 5 ft cable
- Power
- M12 kit (battery and charger)
- Shares photos and video by email over the shop's Wi-Fi
- Draw, add audio or text, and trim video on the device
- Field-replaceable 5 ft cable; HEAT SENSE; 4X zoom
- Kit includes a CP2.0 battery, charger and 32 GB SD card
- More than most home users need
- IP67 appears only on a sell sheet, without saying which part
Built for shops that show customers what they found: a 5.5-inch touchscreen, a 5 mm dual-camera probe on a 5 ft cable, and email straight from the tool over the shop's WiFi.
It's far more than a home mechanic needs, and Milwaukee is vague on water resistance: a sell sheet lists IP67, but not for which part.
Based on the maker's specifications and manual and the published reviews linked below, not on our own test of this unit.
Setup, everyday use and what others found
Setup & use · per the maker
- Kit with a CP2.0 battery, charger, USB-C cable, 32 GB SD card and a carrying case.
- 5.5-inch anti-glare touchscreen with pinch-to-zoom and image rotation.
- 5 mm head with front and side cameras recording 1280 × 720 at 25 fps, on a field-replaceable 5 ft cable; Milwaukee gives a 25 mm bend radius at the camera head and about 5 cm focal distance.
- LEDs adjust through 100 brightness levels.
- Join the shop's WiFi to email findings straight from the tool; files also move by USB-C, USB-A or SD card. You can draw on images, add audio or text, and trim video on the device.
- HEAT SENSE alerts at 75 °C and shuts down at 80 °C. Milwaukee's sell sheet lists IP67 and fuel, oil and solvent resistance without saying which part; the product page gives no rating. Warranty: 5 years on the tool, 2 on the cable and battery.
What others found
The one Home Depot review we could read, a five-star one, notes there's nowhere to stow the camera on the tool while it's connected.
Home Depot review, June 2026
We found no written hands-on test of the 3151-21.
Milwaukee M12 65 ft Ultra Flex Compact Inspection Camera Kit (3318-22A)
Plumbers inspecting small drain lines
- Screen
- None: phone or tablet app, or a Milwaukee monitor
- Camera
- 16 mm, 1080p, 65 ft push cable
- Power
- M12 kit (2 batteries)
- Ultra Flex push cable for 1–3 in drain lines, up to 65 ft
- Sapphire lens and a multi-frequency sonde for locating
- 128 GB storage (upgradeable); ONE-KEY
- Two CP2.0 batteries, a charger and a monitor mount included
- No screen in the box: view on a phone or tablet, or a separately sold Milwaukee monitor
- Rated for 1–3 in lines, not main sewers
The Milwaukee for small drain lines: a 65 ft Ultra Flex cable for 1–3 in pipe, a 1080p head with a locating sonde, and 128 GB of storage, all on M12 batteries.
There's no screen in the box, so you watch on a phone or tablet app or buy Milwaukee's wireless monitor, and it isn't meant for main sewer lines.
Based on the maker's specifications and manual and the published reviews linked below, not on our own test of this unit.
Setup, everyday use and what others found
Setup & use · per the maker
- Kit: the camera reel, two CP2.0 batteries, an M18 and M12 rapid charger, a mount for Milwaukee's M12 Wireless Monitor, a carry strap and two barrel skids. No monitor is included.
- View on a phone or tablet through the Milwaukee Pipeline Inspection app over the reel's built-in WiFi, or on Milwaukee's M12 or M18 Wireless Monitor, sold separately.
- 16 mm, 1080p fixed camera head with a sapphire lens and color-accurate LEDs, plus 4× digital pan and zoom.
- Ultra Flex push cable rated for 1–3 in drain lines, up to 65 ft, with a multi-frequency sonde in the head for locating.
- 128 GB of built-in storage, upgradeable, with USB and USB-C ports; ONE-KEY connected.
- 5-year limited warranty. Milwaukee publishes no IP rating or operating temperature for it.
What others found
We found no hands-on test and no owner reviews we could read for this kit.
- Aeronautics diploma
- Engineering degree
- BAMEC (DGCA)
- QC-trained
- ~2 yrs tool management
Why you should trust us
SK Kutubuddin spent over two decades in aviation maintenance, much of it doing borescope inspection of turbine and compressor blades, and almost two years in a dedicated tool bay, where tools were issued, returned and checked for serviceability. That background shapes how this review weighs Milwaukee's cameras: what the camera can actually show, how tough it is, and what the maker does and does not promise.
We compared Milwaukee's current inspection cameras and checked every figure against Milwaukee's product pages and manuals and the live listing, per our how-we-test method. Where Milwaukee's own sources disagree, as they do on some head sizes and zoom levels, we say so or use the more conservative figure. Milwaukee does not sponsor this page, and it is a buying guide, not a lab test.
Who this is for
This page is for electricians, plumbers, HVAC techs and mechanics already on Milwaukee's M12 platform, and for anyone deciding whether a Milwaukee camera is worth it over a specialist borescope brand.
If you do not use M12 tools and mainly need a thin probe or an articulating tip, our best borescope and inspection camera pages cover specialist scopes.
- M12 users who want a camera on the same batteries
- Tradespeople checking walls, cabinets and ceilings
- Mechanics who need a 5 mm dual-camera probe
- Plumbers looking at small drain lines
How we picked
We chose the Milwaukee camera for each common job and checked each spec against Milwaukee's own pages and manuals.
- 01
The right camera for the job
Milwaukee's range runs from a general-purpose M-Spector to engine borescopes and a drain camera, so we assigned each to the work it suits.
- 02
What is in the box
Milwaukee sells some of these as bare tools and some as kits, so we noted which include batteries, a charger, an SD card or even a screen.
- 03
Honest limits
We recorded what Milwaukee does not publish, such as waterproof ratings, and where its own sources disagree.
- 04
Listings you can buy
We only picked listings under the Milwaukee brand, not look-alike or reseller listings that use Milwaukee's name.
What to know before you buy
Is a Milwaukee inspection camera worth it?
If you already run M12 tools, yes. The M-Spector 360 is a simple, tough jobsite camera with a rotating screen, recording to an SD card and a 5-year tool warranty, and it shares batteries with the rest of your kit.
Its limits are worth knowing. A 10 mm head will not fit small holes, 720p is modest next to many cheaper scopes, and Milwaukee gives no waterproof rating. If you need a thinner probe, a side camera or an articulating tip, a specialist scope such as a Teslong or a Klein Tools model may suit you better.
Which Milwaukee inspection camera should you buy?
Match it to the job:
- Walls, cabinets and general trade work: the M12 M-Spector 360, with a 4 ft (2323-21) or 10 ft (2324-21) cable.
- No M12 batteries: the M-Spector 4 ft (2319-20), which runs on AAs; Milwaukee's page and manual describe a live view only.
- Engines: the M12 Auto Technician Borescope (3150-20), with 5 mm front and side cameras.
- Shops that share inspections with customers: the M12 Auto Shop Borescope with Wi-Fi (3151-21).
- Small drain lines: the M12 65 ft Ultra Flex kit (3318-22A), or the M12 75 ft Drain Camera (3154-20), which has its own 7-inch touchscreen but no sonde.
M-Spector 360: 4 ft or 10 ft?
The 2323-21 and 2324-21 share the same 4.3-inch screen, 10 mm head and 720p camera; only the cable length differs. The 4 ft cable is easier to handle in walls and cabinets. The 10 ft version reaches further into ceilings, crawl spaces and drains, at the cost of more cable to manage.
Care for a Milwaukee inspection camera
Keep the handset dry: Milwaukee's M-Spector manuals say never to immerse the tool, and of these cameras only the Auto Shop borescope's sell sheet lists an IP67 rating, without saying which part. Wipe the camera head and cable after use in drains or engines, coil the cable loosely rather than kinking it, and store the camera in its case.
Frequently asked questions
Is the Milwaukee M-Spector waterproof?
Milwaukee does not publish an IP rating for the M-Spector 360, and its manual says never to immerse the tool. If you need a camera rated for immersion, look for an IP67 or IP68 model.
Does the M12 M-Spector 360 come with a battery?
Milwaukee calls the 2323-21 a kit, but its product page does not list a battery or charger, so check the listing. The 3150-20 is a bare tool; the 3151-21 and 3318-22A kits include batteries and a charger.
Can the M12 M-Spector 360 record video?
Yes. It saves photos and video to an SD card, and Milwaukee includes a 32 GB card. For the AA-powered M-Spector 4 ft (2319-20), Milwaukee's page and manual describe no recording.
What is the difference between the M-Spector 360 and the M-Spector 4 ft?
The M-Spector 360 runs on M12 batteries and records photos and video. The M-Spector 4 ft runs on four AA batteries and, from what Milwaukee lists, offers a live view only.
Which Milwaukee inspection camera is best for cars?
The M12 Auto Technician Borescope (3150-20). Its 5 mm front and side cameras fit narrow engine openings, and HEAT SENSE warns you if the area is too hot.
Is the M12 M-Spector 360 good for plumbing?
For looking a short way into a drain or behind fixtures, yes; Milwaukee includes a plumbing ball. For drain lines beyond a few feet, use a drain camera with a push cable, such as Milwaukee's 65 ft or 75 ft M12 systems.
What warranty does the M12 M-Spector 360 have?
Milwaukee lists a 5-year warranty on the tool and 2 years on the battery.
